Factory Supply Coil Prime quality PPGL PPGI dx51d Q195 color coated steel prepainted steel coil


Available Size:





30% T/T deposit,70% T/T or 70% L/C at sight balance

Product Details

Product namePPGI/ PPGL slited coil PPGI steel strip PPGL steel strip Color coated steel strip
Steel GradeG250-G550
Technical StandardJIS 3312 / ASTM A653
Popular Width750/900/914/1000/1219/1065/1200/1250mm
Thickness0.15mm-2.0mm(0.14-0.6mm is the popular thickness)
Paint brandNippon/Beckers Paint
Paint thicknesstop paint: 10-30um, back side: 5-25um
Paint Surfaceglossy/matt/wrinkled
Surface TreatmentFilm protection or not
Zinc coating30-275g/m2
Gloss30%-80% glossy
ColorRAL color or customer's sample
Weight3-8 MT per coil
ID coil508mm/610mm

Packagesea worthy package
Applicationroofing sheet or steel structure, building
Price termsFOB, CFR, CIF
Payment termsL/C, T/T, D/P
Delivery time15-20 days after received the advance payment



PPGI: is a product made by surface chemical treatment (degreasing, phosphating, chromium-hydrochloric acid passivation) of coated steel plates (galvanized, galvanized, nickel-plated, etc.), then coated with paint, and then baked.

Advantages: It not only has the mechanical strength and easy formability of steel plate, but also has good decoration and corrosion resistance of organic materials. The coating has strong adhesion and can maintain the novel color for a long time.

PPGL:It is made of galvanized steel sheet (55% aluminum, 43% zinc and 1.6% silicon), which is more corrosion resistant than galvanized. After surface degreasing, phosphating, and complex salt treatment, it is coated with organic paint and baked And the products made.

Advantages:Aluminum-zinc color-coated sheets (AZ150, G345A, PVDF) are very suitable for buildings or other facilities in extreme environments. They are highly corrosion-resistant and weather-resistant, and all major steel plants of this type of steel plate can guarantee more than 20 years of use life. In addition, high-strength steel plates have been widely used abroad and have good economic efficiency, which is also a domestic development trend.

Coating type

1. Reinforced polyester (Regular modified polyester, RMP for short)

2. Self-cleaning (Ever Clean, or Self-Clean)

3. Silicon modified polyester (SMP)

4. Hi-Durable polyester (HDP)

5. Fluorocarbon (PVDF)

Coating structure

2/1M  two coats and one bake

2/2M  two coating and two baking

Applicable standards: ASTM A755/M; JIS G3322, etc.


Widely used in various fields such as construction, home appliances, furniture, public facilities and transportation.

1. For constructional exterior curtain walls, ACP of aluminum composite panel, Decorative Renovation Buildings, Building Facades, Siding, Window, Exterior and Interior Cladding Wall Panel, Indoor and Outdoor Ceiling, Roller Shutter Doors, Roofing Material and so on.

2. Eaves Trough, Rain Gutters and Downspouts, Soffits and so on. 3. Decorative renovation for storey-added old buildings, Wallboard and ceilings for tunnels. 4. Channel Letters, Advertisement board, display platforms, LED Signs, UV printing, Advertising Boards, Billboards, Signboards, Wallboards and so on. 5. Raw materials in industrial purpose. 6. Material for Vehicle Bodies, Yacht Bodies, Boat Bodies, Bus Body, and so on. 7. Fan blade sheets, louver window shades blinds.

Packaging & Shipping

Common Package:

Waterproof Kraft Paper + Wooden Pallet (each 3 tons) + Bundle with steel strip.

Or Package can also according to your requirements.

The time of delivery:

Within 7-10 days after receipt of advance payment
