Prepainted galvanized aluminum coil/color coated aluminum sheet in coil

Color Aluminum Sheet/Coil

Available Size:



1000,2000,3000,4000,5000,6000,7000 series


30% T/T deposit,70% T/T or 70% L/C at sight balance

Product Details

Aluminum Alloy/TemperAA1100/H16,AA3003/H18,AA3015/H18,AA5005/H24
Thickness0.15mm --3.0mm
Width50mm--1650mm, other on request
Coil ID∅505 or  ∅405
Single Weight2.5 Ton/Roll or customized
Thickness of  coatingPE coating more than 18μm / PVDF more than 25μm
ColorSolid/metallic color, wooden/marble pattern
Production abilityMonthly 5000 Ton
PackingWrapping or Pallet
Delivery time20 day after getting deposit payment
Payment termsT/T, L/C,Western Union/paypal
ApplicationRaw materials for celling, Aluminium composite panel,aluminium sheet, aluminium signboar,kichen cabinet, display platform,decoration, wall cladding




Color coated aluminum coil is a solution with an excellent acid-resistant material. Coating to maintain a long time. It is an environmentally friendly, fire-resistant properties of the green and beautiful decorative. Color coated aluminum coil are widely used in ACP,curtain panel,honey comb panel,shutter,roofing and most of the decoration areas.
PE(polyester) Coating
PE(polyester) coating: High molecular polymer as monomer and addition of alkyd, is an UV-resistant coating. It can be classified matt and glossy according to coating gloss. The compact molecule structure, makes paint surface luster and smooth,which assure good printing on the panel surface. With an warranty of 8-10 years for weather resistance, it is specially applied for internal decoration and sign board.
PVDF(fluorine-carbon) Coating
PVDF(fluorine-carbon) coating : Made of fluorine carbon resin, pigment, ester solvent, after high temperature roasting and baking, the paint is solidified to dry film with super weather resistance.


1. The surface of the color aluminum plate is flat, and there is no composite high temperature indentation on the surface. There is no residual stress on the board surface and no deformation after shearing.

2. The color-coated aluminum sheet has good mechanical properties, light weight, high strength, and quick and convenient installation and construction. Use high-quality aluminum, plastics and adhesives, and use advanced composite technology. The product has the required bending and flexural strength for decorative panels, and changes in wind pressure, temperature, humidity and other factors in the four seasons of the climate will not cause bending, deformation, expansion, etc.

3. The color-coated aluminum sheet should have good weather resistance, and the paint pattern formed by connecting coating and high-temperature baking, high gloss retention, good color temperature, and many colors, can meet the various color requirements of modern buildings, and color difference The change is minimal. Polyester paint is guaranteed for 10 years, and fluoroester paint is guaranteed for more than 20 years.

4. Color-coated aluminum sheets need to be environmentally friendly and safe. The main component of fluorocarbon polymer coatings is Kynar500 fluorocarbon resin. This fluorocarbon resin has durable binding force and the most stable molecular structure, which determines the fluorocarbon spray treatment The products can resist wind, rain, industrial waste gas, acid rain and other erosions for a long time, and can withstand harsh weather conditions without discoloration, fading, peeling, cracking, pulverization, etc., and the service life exceeds 20 years. Strong low pollution, it is difficult to attach pollutants on the surface, can maintain a long-term smoothness, easy to maintain and clean, does not release any toxic gas, does not cause corrosion of the keel and fixed parts, and is flame retardant.

5. The color-coated aluminum sheet is excellent in decoration and has many shapes. The coating color can be customized according to the needs of customers, giving customers a wide range of individual choices, which can enrich the humanistic connotation of the product and give people more beautiful enjoyment.

Used for Doors and windows, sun rooms, balcony encapsulation and other fields of high-end real estate are widely used. Color-coated aluminum coil has become one of the most popular top-level decorative materials. It is a kind of green with environmental protection, durability and aesthetic characteristics.

Packaging & Shipping

Common Package:

Waterproof Kraft Paper + Wooden Pallet (each 3 tons) + Bundle with steel strip.

Or Package can also according to your requirements.

The time of delivery:

Within 7-10 days after receipt of advance payment
